S1000‑2M is a high‑Tg FR‑4 PCB material from Shengyi Technology, with Tg ≥170°C (DSC: 180°C; DMA: 185°C). Engineered for lead‑free assembly and high‑layer‑count PCBs, it delivers stable thermal performance, excellent through‑hole reliability, and superior processability. Widely used in automotive, computing, communications, industrial, and HDI applications.

High Tg PCB Material S1000-2M Datasheet

High Tg PCB Material S1000-2M

What Is S1000-2M PCB Material?

S1000-2M is a high glass transition temperature (Tg) epoxy laminate developed by Shengyi Technology. It is widely used in multilayer PCB fabrication where thermal reliability, dimensional stability, and CAF resistance are critical.

Compared with standard FR4 materials, S1000-2M PCB material offers improved thermal endurance and mechanical robustness, making it suitable for demanding applications such as automotive electronics, industrial control systems, and high-density PCB assemblies.

Core positioning:

  • Tg: ~170°C (DSC)
  • FR4 class with enhanced performance
  • Designed for multilayer and HDI boards
  • Optimized for lead-free assembly processes

Shengyi S1000-2M Features

  • Lead‑free compatible FR‑4 laminate & prepreg
  • High Tg 170°C+ (DSC), UV blocking / AOI compatible
  • Outstanding heat resistance and high thermal stability
  • Low Z‑axis CTE for improved via reliability
  • Excellent anti‑CAF performance
  • Low water absorption & high temperature/humidity resistance
  • Excellent mechanical machining performance

S1000‑2M Datasheet Values

ParameterTest MethodConditionUnitTypical Value
Tg (DSC)IPC‑TM‑650 2.4.25DSC°C180
Tg (DMA)IPC‑TM‑650 2.4.24.4DMA°C185
Td (5% wt loss)IPC‑TM‑650 2.4.24.6TGA°C355
CTE Z‑axis (before Tg)IPC‑TM‑650 2.4.41ppm/°C41
CTE Z‑axis (after Tg)IPC‑TM‑650 2.4.41ppm/°C208
T260IPC‑TM‑650 2.4.24.1TMAmin60
T288IPC‑TM‑650 2.4.24.1TMAmin30
T300IPC‑TM‑650 2.4.24.1TMAmin15
Thermal StressIPC‑TM‑650 2.4.13.1288°C, solder dips>100s, no delamination
Dk (1GHz)IPC‑TM‑650 2.5.5.91GHz4.6
Df (1GHz)IPC‑TM‑650 2.5.5.91GHz0.018
Peel Strength (1oz HTE)IPC‑TM‑650 2.4.8After 288°C thermal stressN/mm1.3
Water AbsorptionIPC‑TM‑650 2.6.2.1%0.08
FlammabilityUL94RatingV‑0
CTIIEC 60112Level3
Dielectric BreakdownIPC‑TM‑650 2.5.6kV45+
Volume ResistivityIPC‑TM‑650 2.5.17.1After moisture resistanceMΩ·cm8.66E+08
Surface ResistivityIPC‑TM‑650 2.5.17.1After moisture resistance2.17E+07
Flexural Strength (LW)IPC‑TM‑650 2.4.4125°CMPa567
Flexural Strength (CW)IPC‑TM‑650 2.4.4125°CMPa442
Arc ResistanceIPC‑TM‑650 2.5.1s133

Remarks:

1. Specification sheet: IPC-4101/126, is for your reference only.

2. All the typical value is based on the 1.6mm specimen, while the Tg is for specimen≥0.50mm.

3. All the typical values listed above are for your reference only and not intended for specification.

4. E=Temperature conditioning in the table

S1000‑2M PCB Material Applications

  • High‑layer‑count PCBs
  • Automotive electronics
  • Computing & servers
  • Communications equipment
  • Industrial control
  • HDI boards
  • High‑reliability industrial electronics

S1000-2M vs S1000-2: What are Differences?

PropertyS1000-2S1000-2M
Material TypeHigh Tg FR4 epoxy laminateEnhanced high Tg FR4 epoxy laminate
Resin SystemStandard epoxyModified epoxy system
Tg (DSC)~150°C~170°C
Tg (TMA)~160°C~175–180°C
Td (5% weight loss)~320–330°C≥340°C
T260≥30 min≥60 min
T288≥10 min≥15 min
CTE Z-axis (<Tg)~55–60 ppm/°C~45–50 ppm/°C
CTE Z-axis (>Tg)~280–300 ppm/°C~240–260 ppm/°C
Thermal Conductivity~0.30 W/m·K~0.30–0.35 W/m·K
Dielectric Constant (Dk @1GHz)~4.5~4.3–4.5
Dissipation Factor (Df @1GHz)~0.020~0.018–0.020
Volume Resistivity≥1×10⁷ MΩ·cm≥1×10⁷ MΩ·cm
Surface Resistivity≥1×10⁶ MΩ≥1×10⁶ MΩ
Flexural Strength≥400 MPa≥450 MPa
Peel Strength (1 oz Cu)≥0.9 N/mm≥1.0 N/mm
Water Absorption≤0.20%≤0.15%
CAF ResistanceStandardEnhanced
Flammability RatingUL94 V-0UL94 V-0
Lead-Free CompatibilityGoodExcellent
Reflow Cycles (Typical)2–3 cycles3–5 cycles
Max Layer Count (Typical)Up to ~8–10 layersUp to ~12–16+ layers
HDI SuitabilityModerateGood
Warpage ControlStandardImproved
DrillabilityGoodBetter (lower smear)
Application LevelConsumer / general industrialAutomotive / industrial / high reliability
Relative CostLower+5% to +10%

Choose S1000-2 if:

  • Cost is the primary concern
  • Product lifecycle is short
  • Operating temperature is moderate
  • PCB complexity is low (≤6 layers)

Choose S1000-2M if:

  • High reliability is required
  • Multilayer PCB (>6–8 layers)
  • Lead-free soldering is used
  • Product operates in harsh environments
  • Long lifecycle (>5 years) is expected

FAQs About S1000-2M PCB Material

1. What is S1000-2M Tg value?

S1000-2M has a Tg of approximately 170°C, which supports high-temperature PCB applications and lead-free soldering processes.

2. Is S1000-2M suitable for automotive PCBs?

Yes, it is widely used in automotive electronics due to its thermal stability, CAF resistance, and long-term reliability.

3. Is S1000-2M better than standard FR4?

Yes, it offers higher Tg, better thermal resistance, and improved reliability compared to standard FR4 materials.

4. Can S1000-2M be used for high-frequency designs?

It can be used for general digital circuits, but for RF applications, specialized low-loss materials are recommended.

Get S1000-2M Datasheet & PCB Manufacturing Support

If your project requires high-reliability multilayer PCB material, S1000-2M is a proven and cost-effective choice.

At EBest Circuit, we provide:

  • Material selection support
  • Stack-up design optimization
  • Fast PCB & PCBA manufacturing

📩 Email: sales@bestpcbs.com

📞 Tel: +86-755-2909-1601
